Thermofiber 202AF

THERMOFIBER 202AF is a rigid molded asbestos-free brake lining specifically engineered for medium duty industrial applications. TF202AF is composed of rubber, synthetic resins, friction fibers and minerals. TF202AF can be produced integrally molded, mixed molded and on friction bands.

TYPICAL APPLICATIONS Industrial Brakes, Friction Pads for Appliances, Clutches & Oil-Dipped Clutches, Brakes & Clutches for Electric Engines

AVAILABLE FORMS Flat Sheets, Special Molded Pieces

Contact Us for Catalogs & Pricing Download Product Data Sheet Here

friccion06

TF202AF Technical Data

COLOR Grey

STRUCTURE Rigid

COMPOSITION

Metallic No
Aramid No

MAIN FIBER Glass

TYPE OF SERVICE Dry

COEFFICIENT OF FRICTION (μ)

Normal 0.445
Hot 0.400

WEAR RATE Excellent

SHEAR IMPACT STRENGTH High

MECHANICAL RESISTANCE

Tensile Strength 2,289 (ASTM D638-91)
Flexural Strength 11,855 (ASTM D790-97)
Compressive Strength 15,048 (ASTM D695-91)

HARDNESS 80 (Shore-C)

SPECIFIC GRAVITY 1.90

MAX. RUBBING SPEED 7,500 ft/min

MAX. DRUM TEMPERATURE 410 F

MAX. PRESSURE 150 psi

The above test data is provided for informational purposes and represents standards in controlled laboratory settings. Actual performance will vary by application and operating conditions.
