Thermofiber 1490

Home » Industrial Parts » Thermofiber 1490

TF1490

THERMOFIBER 1490 is a flexible resin-bonded material designed for medium/heavy-duty industrial applications.

THERMOFIBER 1490’s soft form allows for silent operation while producing little wear of the friction and the mating surfaces. These properties combined with its high coefficient of friction make THERMOFIBER 1490 highly suited to indoor/warehouse crane brakes and electro-mechanical brake/clutch systems.

AVAILABLE FORMS Roll Lining, Bonding Segments

Contact Us for Catalogs & Pricing Download Product Data Sheet Here

Flexible Molded

TF1490 Technical Data

COLOR Brown

STRUCTURE Flexible

COMPOSITION

Metallic No
Aramid No

MAIN FIBER Glass

TYPE OF SERVICE Dry

COEFFICIENT OF FRICTION (μ)

Normal 0.55

WEAR RATE Very Good

SHEAR IMPACT STRENGTH 2.15 MN/N2 @ 77 F

HARDNESS 68-75

SPECIFIC GRAVITY 1.55

MAX. RUBBING SPEED 25 m/s intermittent

MAX. DRUM TEMPERATURE 590 F

MAX. PRESSURE 180 psi

The above test data is provided for informational purposes and represents standards in controlled laboratory settings. Actual performance will vary by application and operating conditions.
